Quotation Form Reamers

In order to be able to supply you with a quotation, please give as much information as possible. We accept dimensions in Imperial or Metric.

Carbide Reamer Specification

Style
Application
Size range
Standard
tolerance
1200
1.8mm to
13.2
+0.008mm
-0

For most applications.

1200R
1.8mm to
9.6
+0.008mm
-0

Right-hand spiral flutes. For ductile and abrasive materials, blind holes. Do not use on holes with interruptions unless the material is very soft.

1200L
1.8mm to
9.6
+0.008mm
-0

Left-hand spiral. Gives better finish on hard materials, including heat-treated steels and chilled castings. Use for holes with interruptions such as keyways, perforations, etc. Chip will clog on blind holes.

1300
2.9mm to
9.8
+0.008mm
-0

For most applications.

1300R
2.9mm to
9.8
+0.008mm
-0

Right-hand spiral flutes. For ductile and abrasive materials, blind holes. Do not use on holes with interruptions unless the material is very soft.

1300L
2.9mm to
9.8
+0.008mm
-0

Left-hand spiral. Gives better finish on hard materials, including heat-treated steels and chilled castings. Use for holes with interruptions such as keyways, perforations, etc. Chip will clog on blind holes.

SFR
6.05mm to
38.00
+0.008mm
-0

Straight flute straight shank. For all general applications. Carbide tip runs full length of flute for maximum regrinds. Also available with expandable flutes to allow many regrinds.

TFR
6.05mm to
52.00
+0.008mm
-0

Straight flute taper shank. For general applications. Full length tip for deep holes and many regrinds. Also available with expandable flutes to allow many regrinds.

SRSR
6.05mm to
38.20
+0.008mm
-0

Right hand helix flutes. For ductile materials and for blind holes, where the swarf should be drawn back from the cutting edge. The carbide tip is not as long as the straight flute style. In straight shank only.

SLSR
5.60mm
38.20
+0.008mm
-0

Left hand helix flutes. For holes with interruptions and for harder materials that require a negative rake for a better finish, such as heat treated steels and chilled irons. Use on through holes only since the swarf is forced to the head of the tool. In straight shank only.

Please email any special tooling requests to sales@drill-service.co.uk or call 01293 774911 to discuss.
